Goulds V60H HydroPro Diaphragm Tank – Horizontal Model with Bracket, 19.9 Gallons, 6.1 Gal Drawdown at 30/50 PSI, 1" NPTF Connection, 100 PSI Max

The Goulds V60H is a 19.9 gallon HydroPro® diaphragm (bladder) pressure tank -- a horizontal tank with a universal jet pump mounting bracket, for installations with limited headspace such as under mobile homes. It uses a heavy-duty Butyl rubber diaphragm to separate the tank's air charge from the water, delivering 6.1 gallons of usable drawdown at a 30/50 PSI system pressure range.

• Total Volume: 19.9 gallons
• Drawdown at 20/40 PSI: 7.3 gallons
• Drawdown at 30/50 PSI: 6.1 gallons
• Drawdown at 40/60 PSI: 5.3 gallons
• Maximum Drawdown: 12.1 gallons
• Pre-Charge: 38 PSI (factory charged)
• Maximum Working Pressure: 100 PSI
• Maximum Temperature: 120°F
• System Connection: 1" NPTF (stainless steel)
• Diameter: 15-3/8"
• Height: 33-7/8"
• Shipping Weight: 36 lbs
• Interior Lining: fusion-bonded polymeric lining
• Certification: NSF/ANSI 61-G

Construction & Features:

• Shell: Deep-drawn steel for maximum material strength, with an inner shell that prevents the diaphragm from over-expanding
• Diaphragm: Heavy-duty parabolic Butyl rubber diaphragm -- FDA approved and meets NSF/ANSI 61-G, separates air and water to maintain the tank's air charge and reduces abrasive wear for longer diaphragm life
• Exterior Finish: Blue, high-durability powder coat over a zinc phosphate surface treatment
• Certification: NSF/ANSI 61-G certified
• Mounting: Universal jet pump bracket with two bolt-on, corrosion-resistant high density polypropylene feet, for installations with limited headspace such as under mobile homes

Applications: Residential, commercial, and agricultural well water systems -- a horizontal model with bracket for maintaining system pressure and reducing pump cycling.

Installation note: install indoors or in a location protected from rain, irrigation overspray, salt air, and other corrosive environments, and always protect this tank from freezing.
