![Goulds LCC1J2D0 LC Multi-Stage Centrifugal 304L SS 5HP 3PH ODP Model replaced by [10HM04N30T6PBQE]](http://waterpumpspro.com/cdn/shop/files/LCC.jpg?v=1780610156&width=800)
Goulds LCC1J2D0 LC Multi-Stage Centrifugal 304L SS 5HP 3PH ODP Model replaced by [10HM04N30T6PBQE]
See price in cart
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
This item is obsolete
This item is obsolete.
Goulds LCC1J2D0 is a 5 HP, 3-phase, Open Drip-Proof (ODP) close-coupled multi-stage centrifugal pump in the Goulds LC Series (304L stainless steel), 2 stages.
- Part Number: LCC1J2D0
- Horsepower: 5 HP
- Phase: 3-Phase
- Voltage: 115/230V
- Motor Enclosure: Open Drip-Proof (ODP)
- Stages: 2
- Pipe Connections: 1 x 1-1/2 NPT
Pump Features:
- Design: Close-coupled, space-saving design provides easy installation.
- Construction: Fabricated 304 stainless steel, end suction/top discharge, with a case drain provided as standard.
- Impeller: Enclosed design for higher efficiency, positively locked on the shaft with a key and an impeller nut.
- Mechanical Seal: Carbon/ceramic faces, 316 series stainless steel metal components, and Viton elastomer. Optional faces and elastomers available.
Applications: Water circulation, booster services, liquid transfer, spraying systems, general purpose pumping, and jockey pump service.
