Goulds JRD7 Convertible Jet Pump – JRD Series, 3/4 HP, 115/230V, Single Phase, 1-1/4" NPT Suction, 1" NPT Discharge, Cast Iron Body
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
The Goulds JRD7 is a 3/4 HP, 115/230-volt, single-phase convertible jet pump. It can be plumbed for either shallow well or deep well service using the appropriate fittings package, making it a versatile choice for homes, farms, and cottages. Suction is 1-1/4" NPT and discharge is 1" NPT, with a 1" NPT drive connection for deep well pressure control.
- Horsepower: 3/4 HP
- Voltage: 115/230V, Single-Phase
- Pressure Switch: 30-50 PSI (AS4), preset
- Pipe Connections: 1-1/4" NPT suction, 1" NPT discharge, 1" NPT drive
- Overall Length ("C" Max): 11.56"
- Shipping Weight: 42 lbs
- Maximum Liquid Temperature: 140°F (60°C)
Construction & Features:
- Design: Convertible -- may be plumbed for shallow well OR deep well service using the appropriate fittings package
- Casing: Cast iron, back pullout serviceable design
- Impeller: FDA-compliant, glass-filled engineered composite
- Diffuser: Food-grade, glass-filled engineered composite
- Tubing & Fittings: Corrosion-resistant engineered plastic with hand-tight O-ring connections
- Motor: NEMA standard service factors, stainless steel shaft
- Finish: Electrocoat baked paint
- Certification: NSF/ANSI 61 & 372 listed, CSA File #LR38549
Applications: Homes, farms, cottages, and booster service.
Installation note: a pressure tank is required on all systems. Deep well installations require a pressure control valve and the appropriate deep well fittings package (twin pipe or packer). Wiring must be performed by a qualified electrician per local codes and the NEC.
