Goulds D4UGR84 36" Dia. 84" Deep Duplex guide rail system
See price in cart
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Goulds D4UGR84 is a fully assembled duplex guide rail basin system on a 36 inch diameter, 84 inch deep fiberglass basin, where each pump is suspended by its discharge and rides a stainless steel dual-pipe guide rail for removal without entering the basin.
- Configuration: Duplex (2-pump)
- Basin Diameter: 36 in
- Basin Depth: 84 in
- Basin Material: Solid fiberglass, integral antiflotation ring
- Cover: Grass green solid fiberglass
- Electrical Grommet: 1.5 in
- Inlet Grommet: 4 in
- Couplings: (2) brass quick disconnect
- Discharge Pipe: Schedule 40 galvanized steel
- Check Valves: (2) cast iron ball type
- Gate Valves: (2) bronze
- Lifting Cables: (2) 1/4 in stainless steel
- Guide Rail: Dual-pipe stainless steel guide rail assembly
Applications: Intended for deeper duplex installations that require a guide rail (slide-rail) mounting system so pumps can be raised for service without entering the basin.
