Goulds CDD32540N1 Duplex Panels w/thru door disconnect PH3
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
The item is obsolete. Contact us for replacement
The Goulds CDD32540N1 is a three-phase duplex control panel with a through-the-door main disconnect, built to run two alternating pumps in sump, effluent, sewage, or water-transfer systems. It ships in a NEMA 1 enclosure with the motor overload set for a 2.5-4.0 amp range.
- Panel Type: Duplex (2-pump alternating) with through-the-door disconnect
- Phase: 3-Phase (208/230/460/575V, 60 Hz)
- Enclosure: NEMA 1 (general-purpose, indoor)
- Amp Range: 2.5-4.0 A, field-adjustable overload
- Control Switch: 3-position HOA (Hand-Off-Automatic)
- Indicator: Door-mounted green power-on light
- Alternator: Built-in pump alternator, common alarm & auxiliary alarm contacts
Applications: Used to control and protect simplex or duplex sump, effluent, sewage, and water-transfer pumps, with disconnect capability and high-level alarm warning built into the panel.
