Goulds CDD31016N1 Duplex Panels w/thru door disconnect PH3

The item is obsolete. Contact us for replacement

Goulds CDD31016N1 Duplex Panels w/thru door disconnect, Phase 3, Enclosure NEMA1, Amp Range 10-16 SIMPLEX/DUPLEX Wastewater DISCONNECT STYLE PANELS PANEL Features ■ Oversize enclosure to accommodate all options. ■ One main disconnect through-the-door with door interlock, prevents the door from accidentally being opened when the disconnect is in the ON position. Pad-lockable in the OFF position only. ■ A manual lockable disconnect feature on the motor overload protector. Lock not provided. ■ Oversize magnetic contactor. ■ Overload. Ambient compensated bi-metallic (Class 10) motor overload circuit protector. Instantaneous magnetic trip for short circuit protection. Single-phase protection for three-phase motor. Field adjustable within the amp. range. ■ Control transformer with fused primary and fused secondary on all three-phase. Single-phase 115 volt has a fused control circuit. ■ Pump test switch. Three-position HOA (hand-off-automatic). ■ Green light indicates power to pump motor, mounted on the door, ■ Control terminal board, numbered and wired. ■ Layout and schematic CAD diagrams can be provided upon request. ■ Optional alarm circuit may be field modified to use a 115 volt AC external power source. APPLICATIONS Superior quality simplex and duplex liquid level controller, automatically maintains pump operation, includes high level alarm warning for a variety of sump, effluent, sewage and water transfer applications with ability to disconnect power at panels. Specifica tion s – 1Ø an d 3Ø • Accepts single or dual power feed. • Hand-off-automatic (H-O-A) pump selection switch. • On-off control circuit switch. • Oversized magnetic contactor. • Solid state printed circuit control board with float indicator lights. • Main disconnect. • Alternator for duplex version. • Alarm horn. • Auxiliary alarm contacts. • Capacitors for pumps requiring external motor components are not included or available with this panel. Single Phase • Field adjustable for 115 or 230 V, 60 Hz. • Adjustable motor overload protectors redundant to built-in overload in single phase motors. Three Phase • Field adjustable for 208/230/460/575 V, 60 Hz. • 115 V control circuit transformer. • Adjustable motor overload protectors. • Heaters not required.
