Goulds 33GBS1017E4 1 HP 3 Phase 208-230/460V 304 Stainless Steel Multi-Stage Booster Pump - 10-43 GPM, 5 Stage, 1" NPT, TEPE Motor
See price in cart
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Goulds Water Technology 33GBS Series High Pressure Multi-Stage Booster Pump - Model 33GBS1017E4
Key Specifications
- Model Number: 33GBS1017E4
- Horsepower: 1 HP
- Voltage: 208-230/460V
- Phase: Three-Phase
- Speed: 3500 RPM, 60 Hz
- Stages: 5
- Flow Range: 10 - 43 GPM
- Maximum Head (Series): Up to 575 ft. (249 PSI)
- Connections: 1" NPT suction and discharge
Motor
- Frame: NEMA 56J close-coupled
- Enclosure: Totally Enclosed (TEPE)
- Bearings: Ball bearings carry all radial and axial thrust loads
- Duty: Designed for continuous operation
- Protection: Class 20 overload protection must be provided in the starter (starter sold separately)
Construction
- Discharge Head and Motor Adapter: 304 Stainless Steel
- Bowls and Casing: 304 Stainless Steel
- Impellers and Diffusers: Glass-filled engineered composite
- Shaft and Coupling: Stainless steel hex shaft and coupling
- Mechanical Seal: Carbon / Silicon Carbide / Viton
- Casing Seal: O-ring
Operating Limits
- Maximum Liquid Temperature: 160°F (71°C)
- Maximum Inlet Pressure: 75 PSI
- Maximum Lift with Foot Valve: 10 ft.
- Rotation: Clockwise viewed from motor end
- Approx. Shipping Weight: 51 lbs
Features
- Multi-stage design for steady, quiet, vibration-free operation
- Variable capacity - flow can be selected within the recommended range
- Stainless steel wetted construction suited to filtration and RO applications
- Easy disassembly for maintenance with rabbit-lock bowls and O-ring casing seal
Applications
- Pressure boosting and booster service
- Reverse osmosis and filtration systems
- Pressure washing and spray systems
- Evaporative cooling / misters, HVAC and water circulation
- Residential, commercial and agricultural use
