Goulds 1AS15 Aquavar SOLO Constant Pressure Sub Pump Controller

Goulds 1AS15 Aquavar SOLO Constant Pressure Sub Pump Controller NEMA 3R Enclosure: Rainproof, outdoor/indoor rated enclosure. Current Limit Selector Switch: Rotary switch to set current limit to match motor Service Factor Amps(SFA). Dry Well Sensitivity Switch: Choice of low or high sensitivity. Pressure Drop: Choose a 5 or 20 PSI pressure drop for restarts. Low Pressure Cut-Off: Set on or off depending on application. Constant Pressure: Provides consistent pressure even as flow requirements vary. Controller acts as a pump protection and troubleshooting device. Flashing lights indicate system faults. NEMA 3R Enclosure: Rainproof, outdoor/indoor rated enclosure. Current Limit Selector Switch: Rotary switch to set current limit to match motor Service Factor Amps(SFA). Dry Well Sensitivity Switch: Choice of low or high sensitivity. Pressure Drop: Choose a 5 or 20 PSI pressure drop for restarts. Low Pressure Cut-Off: Set on or off depending on application. Constant Pressure: Provides consistent pressure even as flow requirements vary. Controller acts as a pump protection and troubleshooting device. Flashing lights indicate system faults. Controller Temperature Range: Minimum Ambient Temperature: 14F (-10C) Maximum Ambient Temperature: 122F (50C) Input Voltage: single-phase, 230 Volt, two (2) wire grounded system. Output Voltage: 1 Phase, variable voltage, variable frequency, single phase power to the 2-wire or 3-wire motor Speed/Frequency: 30-60 only Enclosure Dimensions: Height: 18.6" Width: 9.9" Depth: 5.3" Packaged Dimensions: Height: 21" Width: 13" Depth: 8" 1AS15 SPECIFICATIONS Unit Weight: 19 lbs. Packaged Weight: 23 lbs. Pressure Set point adjustable from 20 - 85 psi using the standard 100 psi transducer.
