Goulds CentriPro CB15MC3R – Magnetic Contactor Control Box, 15 HP, 230 Volts, 1 Phase, for 6" CentriPro Motors, NEMA 3R

The Goulds CentriPro CB15MC3R is a Magnetic Contactor (MC) pump control box sized for 15 HP, 230-volt, single-phase 6" CentriPro (Hitachi) submersible well pump motors -- built for use with motor number 6M151. A built-in magnetic contactor lets the system run on a standard pressure switch instead of a separate heavy-duty switch or field-installed contactor.

• Horsepower: 15 HP
• Voltage: 230V, Single-Phase
• Use With Motor: 6M151
• Start Capacitor Rating: (Qty. 2) 216-260 MFD / 330V
• Run Capacitor Rating: (Qty. 2) 35 MFD / 440V
• Contactor Rating: 90 A
• Overload Circuit Breaker: 90 A
• Enclosure: Type N3R, indoor/outdoor
• Enclosure Dimensions: 17.5" H x 11" W x 6.7" D
• Shipping Weight: 27 lbs

Features:

• Built-In Magnetic Contactor: Allows use of a standard pressure switch, prolongs switch life, and eliminates the need to source and install a separate contactor
• Voltage Relay: Installer-convenience relay, 230V standard
• Start & Run Capacitors: For starting torque and efficient, quiet operation
• Overload Protection: Manual-reset overload circuit breaker
• Enclosure: Type N3R, rated for indoor or outdoor mounting
• Wiring: Multiple knockouts, two ground terminals

Applications: Commercial, agricultural, and high-capacity residential well systems using a 6" CentriPro (Hitachi) submersible motor.

Compatibility warning: use this control box only with CentriPro (Hitachi) 6" motors. It is not compatible with Franklin Electric 6" motors -- the overloads and capacitors differ from Franklin Electric’s components, and using this control box on a Franklin Electric motor (or a Franklin Electric control box on a CentriPro motor) will void that manufacturer’s warranty. All wiring must be performed by a qualified electrician in accordance with local codes and the National Electrical Code.
