Goulds JRS5H Shallow Well Jet Pump – JRS Series, 1/2 HP, 115/230V, Single Phase, 6.4 GPM at 5 ft (30 PSI), Cast Iron Body
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
The Goulds JRS5H is a 1/2 HP, 115/230-volt, single-phase compact shallow well jet pump with an integral shallow well jet built into the casing, so no separate adapter is needed. This High Pressure variant is tuned for higher discharge pressure at reduced flow. Suction is 1-1/4" NPT and discharge is 1" NPT.
- Horsepower: 1/2 HP
- Voltage: 115/230V, Single-Phase
- Capacity: 6.4 GPM at 30 PSI, 5 ft suction lift
- Pressure Switch: 30-50 PSI (AS4), High Pressure
- Pipe Connections: 1-1/4" NPT suction, 1" NPT discharge
- Overall Length ("C" Max): 10.81"
- Shipping Weight: 37 lbs
- Maximum Liquid Temperature: 140°F (60°C)
Construction & Features:
- Design: Compact -- integral shallow well jet built into the casing, eliminating the need for a separate adapter
- Casing: Cast iron, back pullout serviceable design, with an O-ring casing seal and a drain plug for winterizing
- Impeller: FDA-compliant, glass-filled engineered composite
- Diffuser: Food-grade, glass-filled engineered composite
- Tubing & Fittings: FDA-compliant, UV-resistant engineered plastic with hand-tight O-ring connections; nozzle clean-out plug
- Motor: Two-compartment design; NEMA service factors, stainless steel shaft
- Finish: Electrocoat baked paint
- Certification: NSF/ANSI 61 & 372 listed, CSA File #LR38549
Applications: Homes, cottages, and booster service.
Installation note: a pressure tank is required on all systems. Wiring must be performed by a qualified electrician in accordance with local codes and the National Electrical Code.
