Goulds J15 Convertible Jet Pump – J+ Series, 1-1/2 HP, 115/230V, Single Phase, 1-1/4" NPT Suction, 1" NPT Discharge, Cast Iron Body

The Goulds J15 is a 1-1/2 HP, 115/230-volt, single-phase convertible jet pump. It can be plumbed for either shallow well or deep well service using the appropriate fittings package, making it a versatile choice for homes, farms, and cottages. Suction is 1-1/4" NPT and discharge is 1" NPT, with a 1" NPT drive connection for deep well pressure control.

• Horsepower: 1-1/2 HP
• Voltage: 115/230V, Single-Phase
• Capacity: 26.6 GPM at 30 PSI, 5 ft suction lift
• Pressure Switch: 30-50 PSI (AS4), preset
• Pipe Connections: 1-1/4" NPT suction, 1" NPT discharge, 1" NPT drive
• Length Overall (shallow well): 24"
• Shipping Weight: 68 lbs
• Maximum Liquid Temperature: 140°F (60°C)

Construction & Features:

• Design: Convertible -- may be plumbed for shallow well OR deep well service using the appropriate fittings package
• Casing: Cast iron, back pullout serviceable design
• Impeller: FDA-compliant, glass-filled engineered composite
• Diffuser: Bolt-down, with stainless steel wear ring
• Tubing & Fittings: Corrosion-resistant engineered plastic with hand-tight O-ring connections; nozzle clean-out plug in the shallow well adapter
• Motor: Two-compartment design; NEMA standard, stainless steel shaft
• Mechanical Seal: Diaphragm-protected -- never runs dry; excellent air-handling and re-prime ability
• Finish: Electrocoat baked paint
• Certification: NSF/ANSI 61 & 372 listed (jet pump and shallow well components)

Applications: Homes, farms, cottages, and booster service.

Installation note: a pressure tank is required on all systems. Deep well installations require a pressure control valve and the appropriate deep well fittings package (twin pipe or packer). Wiring must be performed by a qualified electrician per local codes and the NEC.
