Goulds CentriPro CB15412CR – Simplex CSCR Control Box, 1-1/2 HP, 230 Volts, 1 Phase, Indoor/Outdoor NEMA 3R
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
The Goulds CentriPro CB15412CR is a CSCR (Capacitor Start-Capacitor Run) pump control box sized for 1-1/2 HP, 230-volt, single-phase, 3-wire submersible well pump motors. It houses the starting and running components a 3-wire motor needs to run on a single-phase circuit, in a NEMA 3R enclosure suitable for indoor or outdoor installation.
- Horsepower: 1-1/2 HP
- Kilowatts: 1.1 kW
- Voltage: 230V, Single-Phase
- Motor Type: 3-wire submersible
- Standard Circuit Breaker: 30 A
- Standard Fuse: 35 A
- Dual-Element Time-Delay Fuse: 20 A
- Enclosure: NEMA 3R, indoor/outdoor
- Enclosure Dimensions (W x D x H): 8.1" x 5.9" x 9.3"
- Shipping Weight: 7 lbs
- May Replace Franklin Electric #: 2823008110
Features:
- Voltage Relay: Installer-convenience relay (230V standard; 208V relay, part 9K479, available for low-voltage applications)
- Start Capacitor: For starting torque
- Run Capacitor: For efficiency and quiet operation (Capacitor Start-Capacitor Run design)
- Enclosure: Type 3R, rated for indoor or outdoor mounting, accepts up to #2 AWG wire
- Wiring: Multiple knockouts, two ground terminals
- Pressure Switch Note: Higher-HP models require a heavy-duty pressure switch
Applications: Residential and light-commercial single-phase well pump installations using a 4", 3-wire submersible motor -- private water systems, domestic water supply, and small booster applications.
Installation note: for use with 3-wire, single-phase submersible motors only -- select the control box rated for the motor’s HP and supply voltage. All wiring must be performed by a qualified electrician in accordance with local codes and the National Electrical Code.
